Genset Model

KG1-62.5WS

Frequency

HZ

50

Power factor

Lagging

0.8

Voltage

V

415(3Ø )

Governing class (As per ISO 8528 part-V)

G2

Noise level

dBA

<75

Fuel Consumption*

At 100%  load

Ltrs/Hr

14.1

At 75% load

11.3

At 50% load

7.5

Fuel tank capacity

Ltrs

150

Overall dimensions of genset (LxWxH)^

mm

2900x1100x1581

Dry Weight of genset with canopy (approx..)^

kg

1420

Wet weight of genset with canopy(approx...)^

kg

1550

Electrical Battery starting voltage

Volts-DC

12

Rated output(prime Continuous rating as per ISO 8528-1)

Kw

61.0

Hp

83

NO. of cylinder

Number

4

Cubic capacity2

Ltrs

3.24

Bore x stroke

Mm

96x112

Rated speed

RPM

1500

Aspiration

NA/TC/TA

TA

Lube Oil change period

Hrs

500

Lube oil sump capacity Max

Ltrs

10.0

Coolant Capacity

Volts-DC

17.5

Altemator Efficiency (at 100% load) 0.8pf**

%

91.0

Max Voltage Dip at full load 0.8 pf lag

Sec

<20%

Max Time to build up rated voltage at rated RPM

Voltage recovery time 6 sec

< 1 sec provided engine reach the rated speed
