| Description | Sunbeam Technical Specifications |
|---|---|
| Model | Sunmix 60+ |
| Output Theoretical | 60 m3 / hr |
| Aggregate Storage | In-Line / Square(Cross bin) |
| Aggregate Weighing | Conveyor |
| Aggregate Bin Capacity per bin | 10 m3 |
| Maximum Aggregate Weighing | 2500 Kg |
| Maximum Cement Weighing | 750 Kg |
| Maximum Water Weighing | 375 Kg |
| Total Aggregate Storage Bins | 4 + 1 |
| Maximum Number of Cement Storage | 2+1 |
| Admix Weighing Capacity | 30 Kg |
| Operating Voltage & Frequency | 415 V ± 10 V , 50 Hz |
| Aggregate Charging Type | Chevron belt Conveyor (Optl. Waiting Hopper ) / Skip hoist |
| Mixer ( SICOMA) | Twinshaft / Planetary/ Panmixer |
| Mixer Capacity | 1 m3 |
| Maximum size of Aggregates | 80 mm |
| Water Sprinkling and Gravity Discharge System | Yes |
| Control system With Phoenix PLC | Automatic |
| IOT - Smart Monitoring | Yes |
| Discharge Height | 4.1 m |
| Unique Selling Points | Low Operating Cost, Low Maintenance, Compact, Intelligent Controls,Better Output than competitors |
| Total Load Cells For Aggregate | 4 Nos, S-type |
| Total Load Cells For Cement hopper | 3, S-Type |
| Total Load Cells For Water hopper | 3, S-Type |
| Total Load Cells For Admix container | 1 , Cantilever Beam |
| Air Compressor Capacity | 2.2 KW , 360 Lpm |
| Mixer Motor Power | 37 KW |
| Hydraulic Pump | 1.5 KW |
| Aggregate Weighing conveyor Power | 12 KW |
| Inclined Conveyor Motor Power | 15 KW |
| Water pump Discharge and Cleaning System | 5 KW |
| Vibrator motor Power- Aggregate Bin (Sand) | 0.18 KW |
| Vibrator motor Power - Cement Hopper | 0.18 KW |
| Admixture Pump Power | 0.75 KW |
| Screw Conveyor Power | 11 KW / 15 KW |
| Total Power Required | 107.31 KW |
| Generator Required | 180 KVA |
